KYX4003V超聲波汽相清洗機系統具有獨立的溶劑回收槽，使漂洗槽內自動補充潔凈的蒸餾溶劑，溶劑反復使用，降低成本。適用于電子零件、小五金、沖壓件及精密機械零件、軸承的油脂、拋光臘及污垢的除。
1、 配有獨立的制冷系統，有效防止溶劑揮發。
2、 設置液位安全控制系統，保證設備正常工作。
3、 設置溶劑過濾系統，保證設備正常工作。
4、 設置溶劑加熱和自動恒溫系統，恒溫范圍為20℃—90℃(可調)。
5、 自動補液系統使用方便。
6、 根據需要，可配置機械臂操作系統。

KYX4003V vapor phase cleaning system has independent solution recovery channel to supplement the clean distilled solution automatically.
In the washing channel.The solution can be used circuitously to reduce the cost. It is suitable for getting rid of grease and dirt on eloctric parts, hardware,precision device and bearings.
1 Independent cool water system to prevent solution form volatilizing.
2 Level safe control system to ensure the instrument operating normally.
3 Solution filter system to ensure the instrument operating normally.
4 Solution heating and –constant –temperture system. The thermostant rangs is 20℃-90℃(adjustable).
5 Auto-supplement solution system is used conveniently.
6 The mechanical arm operation system can be fixed according to need.

【應用范圍】
電子零件及線路板上的松香，粉末冶金件上的防銹油，空調蒸發器，精密機械零件上的油脂表帶表殼上的污垢等的清洗。
【Scope】
Onelectronic part and line board rosin, powder metallurgy on pickling oil, air conditioning evaporator, in
precision machinery components fat watch band watch case's dirt and so on clean.
【產品特點】
1、全不銹鋼結構，結構緊湊合理，美觀大方。
2、加熱及自動恒溫系統，恒溫范圍30℃-110℃（可調）
3、外置工業冷氣機及內置冷凝盤管，有效地防止清洗劑揮發，降低使用成本。
4、另設有蒸餾回收系統，清洗劑可循環再用。
5、設有檢測及安全保護，液位保護，溫度保護，冷氣機過載保護等。
6、設置溶劑過濾系統，確保溶劑的清潔。
7、另可根據客戶不同需求設置自動化機械臂系統。
【Product characteristic】
1、 It made of imported stainless steel plate and components,
all stainless steel structure,looks good and durable.
2、Heating and automatic temperature control system, the
temperature range of 30。C ~110。C (adjustable).
3、External industrial chiller and inside cooling coil units,
Effectively prevent the cleaning agent volatile to reduce the
production cost.
4、It has the distillation recovery system,cleaning agent
that can be reused.
5、It has the detection and security protection,respectively has the level protection,temperature control,chiller overload
protection and so on.
6、Provide filtration system to ensure cleanliness solution.
7、It can increase robotic arm system according to the automer’s automation request.

工藝流程：超聲清洗→超聲漂洗→冷漂洗→冷凝干燥
